The TCA Heat Pump Drying Room is a high‑efficiency, energy‑saving and environmentally friendly modern drying equipment that uses heat pump technology for low‑temperature circulating drying. It is suitable for food, chemical, pharmaceutical, agricultural and other industries, capable of drying granular, flaky, powdery and other forms of materials. The drying room is equipped with professional material carts, uniform hot‑air circulation, and a defrosting system to ensure stable operation under low‑temperature conditions. The whole unit is made of 304 stainless steel support structures, strong and corrosion‑resistant, meeting food‑grade hygiene standards. Double doors facilitate material loading/unloading and internal cleaning, making it an ideal replacement for traditional coal/gas fired drying rooms.
Working Principle
The heat pump dryer uses a compressor to drive refrigerant circulation, absorbing heat from the ambient air and heating the circulating air through a heat exchanger. Hot air is sent into the drying room via the air supply vent, and the circulation fan ensures uniform hot air flow through the material, carrying away moisture. The moist air is dehumidified and reheated for closed‑loop drying. The defrosting system automatically removes frost from the evaporator surface in low‑temperature conditions, ensuring stable operation around the clock.
| No. | Component | Function |
|---|---|---|
| 1 | Heat pump dryer | Provides heat source, generates hot air via compressor and heat exchanger |
| 2 | Air supply vent | Evenly distributes hot air into the drying room |
| 3 | Circulation fan | Forces air circulation to ensure uniform heating of materials |
| 4 | Inlet/outlet hose | Connects heat pump unit to the drying room, transfers hot air |
| 5 | Material cart | Multi‑layer stainless steel racks for holding materials to be dried |
| 6 | Defrosting system | Automatically removes frost under low temperature to prevent evaporator icing |
| 7 | Double door | Facilitates material cart entry/exit, provides sealing and insulation |
| Component | Specification |
|---|---|
| 304 support bracket (square tube) | 20×40 mm flat welded |
| Base | 4000×430×120 mm |
| Back bracket | 2000×200×2020 mm (two pieces) |
| Fixing brackets | 12 pieces |
| Main material | 304 stainless steel |
| Drying room dimensions (reference) | Customizable, typical: 4000×2000×2200 mm |
Technical Parameters
| Parameter | Value |
|---|---|
| Model | TCA-HP-10 / TCA-HP-20 / Customizable |
| Heating method | Heat pump (electric driven) |
| Temperature range | 30‑80℃ (adjustable) |
| Temperature accuracy | ±2℃ |
| Drying capacity (per batch) | 100‑500 kg (depending on material) |
| Heat pump power | 3‑15 kW (by model) |
| Circulation fan power | 0.55‑2.2 kW |
| Defrosting method | Automatic reverse‑cycle defrost |
| Power supply | 380V / 50Hz three‑phase |
| Drying room material | Inner wall 304 stainless steel / Outer wall color steel or stainless steel |
| Insulation layer | Polyurethane foam, thickness 50‑75mm |
| Material cart | 304 stainless steel, swivel casters, customizable number of trays |
Applicable Materials
Fruits & Vegetables：Apple, pear, mango, banana, chili, mushroom, carrot, spinach, etc.
Meat products：Beef jerky, pork jerky, meat floss, cured meat, dried fish, etc.
Cereals：Rice, wheat, corn, beans, etc.
Others：Herbal medicine, spices, flowers, tea leaves, pet treats, etc.
FrequentlyAskedQuestions
我们为完整的加工线提供长期的售后支持，包括技术咨询、故障排除帮助、备件供应和系统升级建议。提供详细的操作手册和维护指南，确保日常操作顺利进行。
我们的解决方案服务通常包括工艺分析、设备配置、生产线布局图、操作指导和技术支持。根据要求，我们还可以通过在线支持协助安装指导、调试和操作员培训。
我们根据您的工厂布局、加工能力和生产要求提供定制解决方案。我们的工程团队可以协助生产线设计和技术规划。
该设备设计用于处理不同尺寸的土豆。对于切割或去皮等某些工艺，可以提供可调节的设置或尺寸分级解决方案，以确保一致的输出质量。
该机器设计用于加工各种食品原料。根据具体型号，它可以处理规定尺寸和湿度范围内的新鲜、冷藏或冷冻材料。为了获得最佳性能，我们建议在订购前确认原材料规格。
